LCO2 Vacuum Insulated Pipeline

Product Overview

The LCO₂ vacuum insulated pipeline is a cryogenic transfer system designed using high-vacuum multi-layer insulation technology. It is specifically used for the efficient transportation of cryogenic liquids such as liquid oxygen, liquid nitrogen, liquid argon, and liquid carbon dioxide.

The pipeline adopts a double-layer structure, forming a high-vacuum environment in the interlayer and incorporating multi-layer insulation materials, which significantly reduces cold loss. It serves as a highly efficient alternative to conventional insulated pipelines under cryogenic conditions.

This system is particularly suitable for medium- to long-distance cryogenic liquid transfer, offering both energy efficiency and reliable operation.

Working Principle

The pipeline is based on high-vacuum multi-layer insulation principles. A stable high-vacuum environment is established between the inner and outer pipes, combined with multiple layers of reflective insulation materials.

This design effectively suppresses heat transfer through conduction, convection, and radiation, thereby significantly reducing heat leakage.

During operation, cryogenic liquids maintain a stable low-temperature state while flowing through the pipeline, minimizing vaporization loss. A reliable sealing structure ensures long-term vacuum stability, while optimized structural design guarantees continuous and stable performance under complex working conditions.

Product Features

• Extremely Low Heat Loss:Heat leakage is only about 035–0.05 times that of conventional insulated pipelines, significantly improving thermal performance.
• Long Service Life:Mechanical service life up to 10–15 years, with vacuum service life exceeding 5–10 years, reducing maintenance costs.
• Multiple Connection Methods:Supports vacuum bayonet connection, vacuum flange connection, and welding connection for flexible installation.
• Easy Maintenance:Optimized structural design ensures simple maintenance and long-term stable operation.
• High Energy Efficiency:Effectively reduces evaporation loss of cryogenic media and improves overall system efficiency.
• Reliable Structure:Double-layer stainless steel construction ensures safety and reliability under cryogenic and pressure conditions.

Applications

• Industrial Gas Transfer：Used for safe and efficient transportation of liquid oxygen, nitrogen, argon, and liquid CO₂.
• Chemical Industry：Provides stable cryogenic media transfer solutions for chemical production processes.
• Medical Industry：Applied in medical gas systems for cryogenic transfer and distribution.
• Cold Chain Logistics：Ensures stable media conditions in low-temperature transport systems, supporting cold chain applications.
• Research Institutions：Supplies reliable cryogenic gas and liquid transfer for laboratory and scientific research projects.
